Enerpac Multi-Point Lifting Systems

Control several hydraulic lifting points from one coordinated system. Enerpac SFP split-flow pumps, EVO synchronous lifting systems and EVOP pump-per-point systems cover economical equal-flow lifting through PLC-controlled high-accuracy synchronized lifting for major structures and high-tonnage loads.

Northland can help match the lifting system to the load, cylinder capacities, required stroke, number of lifting points, synchronization tolerance, lift speed and site power.

SFP • EVO • EVOP

Three levels of multi-point hydraulic control.

SFP Split-Flow2, 4, 6 or 8 equal-flow outlets for controlled multi-cylinder lifting and lowering.
EVO SynchronousPLC-controlled 4, 8 or 12-point systems; network up to 48 lift points.
EVOP Pump-per-PointOne pump for each cylinder when high flow and faster synchronized lifting are required.
10,000 psi SystemsMatch system oil volume, flow, cylinders, hoses, sensors and controls before the lift.
MULTI-POINT LIFTING

Control Load, Stroke & Movement Across Multiple Lift Points

Multi-point lifting systems are used when a structure or machine must be raised, lowered, levelled or positioned from several hydraulic cylinders. The right control method depends on how closely the cylinders must remain synchronized, how fast the load must move, the total oil volume required and whether the lift needs load/stroke feedback or recorded data.

SFP-SeriesEqual-flow split pump for 2–8 cylinders; economical controlled lifting and lowering.
EVO-SeriesClosed-loop PLC control for 4, 8 or 12 points with network capability to 48.
EVOP-SeriesOne pump per cylinder for heavy, high-speed and long-stroke synchronized lifts.
WHICH SYSTEM FITS?

SFP vs. EVO vs. EVOP

The best system is not just a question of tonnage. Synchronization tolerance, stroke length, number of lift points and required speed can change the correct approach.

SFPBest starting point when multiple cylinders need controlled equal-flow movement and approximately 4% synchronization is acceptable. SFP systems can also be upgraded with feedback and network controls for tighter synchronization.
EVOChoose EVO for closed-loop synchronized lifting with PLC control, stroke/load limits, data logging and accuracy down to 0.040 in. between lift points, depending on the cylinders used.
EVOPChoose EVOP when one pump per cylinder and high rated-pressure flow are needed for high-tonnage, long-stroke or repetitive synchronized lifting.
QUICK MODEL SEARCH

Find an Enerpac multi-point lifting model

Try SFP403SJ, SFP813SJ, EVO840460, EVO1240460, EVOP140150J, CLNC12 or EVO-WSS-1000.

CONTROLLED MULTI-CYLINDER FLOW

SFP-Series Split-Flow Pumps

An economical multi-point lifting option that divides hydraulic flow across multiple outlets.

2 / 4 / 6 / 8 outlets20–154 in³/min per outlet10,000 psiManual or pendant
+
WHERE IT FITSUse SFP when multiple cylinders need controlled equal-flow lifting or lowering and the job does not require the full closed-loop capability of an EVO system.
ENERPAC

SFP-Series Split-Flow Pumps

9 VARIATIONS

SFP pumps divide flow across 2, 4, 6 or 8 outlets for controlled multi-cylinder lifting and lowering. Each circuit includes pressure monitoring and adjustable pressure relief; solenoid models add pendant control.

Maximum Operating Pressure10,000 psi
Split-Flow Outlets2, 4, 6 or 8
Usable Reservoir Sizes2.5, 10 or 40 gal
Flow per Outlet at 10,000 psi20–154 in³/min
Standard SFP SynchronizationUse where up to approximately 4% synchronization difference is acceptable
COMMON APPLICATIONSBridge deck lifting for bearing work, stage lifting, structural levelling, wind-turbine levelling, skidding and other multi-cylinder lifts where equal-flow control is suitable.
COMMON INDUSTRIESBridges and infrastructure, construction, shipbuilding, wind energy, heavy transport, industrial maintenance.
Select a model aboveIts specifications will appear here.
VIEW ALL 9 MODELS & FULL SPECIFICATIONSSFP-Series Split-Flow Pumps
+
SFP202MB+
SFP-Series Split-Flow Pumps

SFP202MB

REQUEST INFO →
Split-Flow Outlets2
Usable Oil Capacity2.5 gal
Oil Flow per Outlet at 10,000 psi20 in³/min
Valve OperationManual joystick; 4/3 advance / hold / retract
Motor1.0 hp; 115 V, 1-phase, 60 Hz
Overall Height (A)29.4 in.
Overall Width (B)17.7 in.
Overall Length / Depth (C)27.6 in.
Weight253 lb
SFP403MJ+
SFP-Series Split-Flow Pumps

SFP403MJ

REQUEST INFO →
Split-Flow Outlets4
Usable Oil Capacity10 gal
Oil Flow per Outlet at 10,000 psi22 in³/min
Valve OperationManual joystick; 4/3 advance / hold / retract
Motor3.0 hp; 460 V, 3-phase, 60 Hz
Overall Height (A)40.0 in.
Overall Width (B)25.2 in.
Overall Length / Depth (C)38.2 in.
Weight565 lb
SFP403SJ+
SFP-Series Split-Flow Pumps

SFP403SJ

REQUEST INFO →
Split-Flow Outlets4
Usable Oil Capacity10 gal
Oil Flow per Outlet at 10,000 psi22 in³/min
Valve Operation24 V solenoid; pendant; 4/3 advance / hold / retract
Motor3.0 hp; 460 V, 3-phase, 60 Hz
Remote ControlPendant with 16 ft cord
Overall Height (A)40.0 in.
Overall Width (B)25.2 in.
Overall Length / Depth (C)38.2 in.
Weight565 lb
SFP409SJ+
SFP-Series Split-Flow Pumps

SFP409SJ

REQUEST INFO →
Split-Flow Outlets4
Usable Oil Capacity40 gal
Oil Flow per Outlet at 10,000 psi66 in³/min
Valve Operation24 V solenoid; pendant; 4/3 advance / hold / retract
Motor7.5 hp; 460 V, 3-phase, 60 Hz
Remote ControlPendant with 16 ft cord
Overall Height (A)53.4 in.
Overall Width (B)23.8 in.
Overall Length / Depth (C)45.7 in.
Weight1,045 lb
SFP414SJ+
SFP-Series Split-Flow Pumps

SFP414SJ

REQUEST INFO →
Split-Flow Outlets4
Usable Oil Capacity40 gal
Oil Flow per Outlet at 10,000 psi103 in³/min
Valve Operation24 V solenoid; pendant; 4/3 advance / hold / retract
Motor10 hp; 460 V, 3-phase, 60 Hz
Remote ControlPendant with 16 ft cord
Overall Height (A)53.4 in.
Overall Width (B)23.8 in.
Overall Length / Depth (C)45.7 in.
Weight1,078 lb
SFP421SJ+
SFP-Series Split-Flow Pumps

SFP421SJ

REQUEST INFO →
Split-Flow Outlets4
Usable Oil Capacity40 gal
Oil Flow per Outlet at 10,000 psi154 in³/min
Valve Operation24 V solenoid; pendant; 4/3 advance / hold / retract
Motor15 hp; 460 V, 3-phase, 60 Hz
Remote ControlPendant with 16 ft cord
Overall Height (A)53.4 in.
Overall Width (B)23.8 in.
Overall Length / Depth (C)45.7 in.
Weight1,311 lb
SFP613SJ+
SFP-Series Split-Flow Pumps

SFP613SJ

REQUEST INFO →
Split-Flow Outlets6
Usable Oil Capacity40 gal
Oil Flow per Outlet at 10,000 psi95 in³/min
Valve Operation24 V solenoid; pendant; 4/3 advance / hold / retract
Motor15 hp; 460 V, 3-phase, 60 Hz
Remote ControlPendant with 16 ft cord
Overall Height (A)53.4 in.
Overall Width (B)31.7 in.
Overall Length / Depth (C)47.2 in.
Weight1,236 lb
SFP803SJ+
SFP-Series Split-Flow Pumps

SFP803SJ

REQUEST INFO →
Split-Flow Outlets8
Usable Oil Capacity10 gal
Oil Flow per Outlet at 10,000 psi22 in³/min
Valve Operation24 V solenoid; pendant; 4/3 advance / hold / retract
Motor5.4 hp; 460 V, 3-phase, 60 Hz
Remote ControlPendant with 16 ft cord
Overall Height (A)45.8 in.
Overall Width (B)32.7 in.
Overall Length / Depth (C)43.8 in.
Weight990 lb
SFP813SJ+
SFP-Series Split-Flow Pumps

SFP813SJ

REQUEST INFO →
Split-Flow Outlets8
Usable Oil Capacity40 gal
Oil Flow per Outlet at 10,000 psi95 in³/min
Valve Operation24 V solenoid; pendant; 4/3 advance / hold / retract
Motor20 hp; 460 V, 3-phase, 60 Hz
Remote ControlPendant with 16 ft cord
Overall Height (A)53.4 in.
Overall Width (B)31.7 in.
Overall Length / Depth (C)47.2 in.
Weight1,364 lb
UPGRADE & NETWORK

SFP Network & Synchronous-Lift Upgrades

Add common control, pressure feedback and stroke sensing to one or several SFP pumps.

Up to 4 pumpsUp to 32 cylindersPressure + stroke feedback0.040 in. sync capability
+
WHERE IT FITSUse SFP Synchro/Network components when an existing split-flow system needs tighter synchronization, one operator station or additional lifting points.
ENERPAC

SFP Network & Synchronous-Lift Components

8 VARIATIONS

SFP control components let one pump or several networked split-flow pumps operate from a common control system and can add pressure/stroke feedback for synchronized lifting.

Networked SFP PumpsUp to 4 pumps
Maximum Synchronized Lifting PointsUp to 32 cylinders
Synchronized AccuracyUp to 0.040 in. / 1.0 mm with the synchronous-lift upgrade
COMMON APPLICATIONSUpgrading existing SFP systems, networking several SFP pumps, or adding stroke and pressure feedback for more precise multi-point lifting.
COMMON INDUSTRIESInfrastructure, construction, heavy lifting, plant maintenance, transport and structural positioning.
Select a model aboveIts specifications will appear here.
VIEW ALL 8 MODELS & FULL SPECIFICATIONSSFP Network & Synchronous-Lift Components
+
SFPKMN+
SFP Network & Synchronous-Lift Components

SFPKMN

REQUEST INFO →
TypeMaster control box
UseControls multiple networked SFP pumps in standard operation
Operator InterfaceCentral control station
SFPKSN+
SFP Network & Synchronous-Lift Components

SFPKSN

REQUEST INFO →
TypeJunction box
UseOne per SFP pump when networking multiple pumps in standard operation
SFPKSS4+
SFP Network & Synchronous-Lift Components

SFPKSS4

REQUEST INFO →
TypeJunction box
Lifting Points2–4
UseCollects pressure and stroke sensor signals for synchronized lifting
SFPKSS8+
SFP Network & Synchronous-Lift Components

SFPKSS8

REQUEST INFO →
TypeJunction box
Lifting Points6–8
UseCollects pressure and stroke sensor signals for synchronized lifting
SFPSSC+
SFP Network & Synchronous-Lift Components

SFPSSC

REQUEST INFO →
TypeSingle slave control box
UseUsed when upgrading one SFP pump to synchronous lifting
SFPKPT+
SFP Network & Synchronous-Lift Components

SFPKPT

REQUEST INFO →
TypePressure transducer kit
Quantity1 per cylinder A-port
UseProvides pressure feedback to synchronized controls
SFPCOMM-25+
SFP Network & Synchronous-Lift Components

SFPCOMM-25

REQUEST INFO →
TypeCommunication cable
Length82 ft / 25 m
UseLinks SFP pump controls
EVOMASTER+
SFP Network & Synchronous-Lift Components

EVOMASTER

REQUEST INFO →
TypeMaster control box
UseControls multiple SFP pumps in a networked synchronous-lifting setup
PLC SYNCHRONIZED LIFTING

EVO-Series Synchronous Lifting Systems

The multi-functional synchronized lifting platform for 4, 8 or 12 lifting points per hydraulic power unit.

4 / 8 / 12 pointsUp to 48 networkedPLC controlled0.040 in. accuracy
+
WHERE IT FITSUse EVO when load balance, stroke control, data recording and precise multi-point movement are critical to the lift.
ENERPAC

EVO-Series Synchronous Lifting Systems

6 VARIATIONS

PLC-controlled multi-point lifting systems with variable-frequency motor control, integrated 10,000 psi hydraulic power, data recording and automatic stroke/load limits.

Lifting Points4, 8 or 12 per unit; network up to 48 points
Maximum Operating Pressure10,000 psi
Usable Oil Capacity66 gal
Synchronization AccuracyUp to 0.040 in. / 1.0 mm between lifting points, depending on cylinder capacities
ControlPLC + variable frequency drive motor
DataDisplay, storage and user-defined recording intervals
COMMON APPLICATIONSPrecision bridge and structural lifting, levelling, weighing, lowering, super-lift operations and projects where multiple cylinders must stay closely synchronized.
COMMON INDUSTRIESInfrastructure, bridge construction, offshore and marine, heavy transport, civil construction, power generation and industrial projects.
Select a model aboveIts specifications will appear here.
VIEW ALL 6 MODELS & FULL SPECIFICATIONSEVO-Series Synchronous Lifting Systems
+
EVO421460+
EVO-Series Synchronous Lifting Systems

EVO421460

REQUEST INFO →
Lifting Points4
Variable Oil Flow below 1,800 psi243–812 in³/min
Variable Oil Flow above 1,800 psi46–153 in³/min
Usable Oil Capacity66 gal
Motor4 hp
Motor Speed / ControlVFDM; variable frequency drive 15–60 Hz
Electrical Supply460–480 V, 3-phase, 50–60 Hz
Weight2,000 lb
EVO440460+
EVO-Series Synchronous Lifting Systems

EVO440460

REQUEST INFO →
Lifting Points4
Variable Oil Flow below 1,800 psi285–951 in³/min
Variable Oil Flow above 1,800 psi88–292 in³/min
Usable Oil Capacity66 gal
Motor10 hp
Motor Speed / ControlVFDM; variable frequency drive 15–60 Hz
Electrical Supply460–480 V, 3-phase, 50–60 Hz
Weight2,210 lb
EVO821460+
EVO-Series Synchronous Lifting Systems

EVO821460

REQUEST INFO →
Lifting Points8
Variable Oil Flow below 1,800 psi243–812 in³/min
Variable Oil Flow above 1,800 psi46–153 in³/min
Usable Oil Capacity66 gal
Motor4 hp
Motor Speed / ControlVFDM; variable frequency drive 15–60 Hz
Electrical Supply460–480 V, 3-phase, 50–60 Hz
Weight2,000 lb
EVO840460+
EVO-Series Synchronous Lifting Systems

EVO840460

REQUEST INFO →
Lifting Points8
Variable Oil Flow below 1,800 psi285–951 in³/min
Variable Oil Flow above 1,800 psi88–292 in³/min
Usable Oil Capacity66 gal
Motor10 hp
Motor Speed / ControlVFDM; variable frequency drive 15–60 Hz
Electrical Supply460–480 V, 3-phase, 50–60 Hz
Weight2,000 lb
EVO1221460+
EVO-Series Synchronous Lifting Systems

EVO1221460

REQUEST INFO →
Lifting Points12
Variable Oil Flow below 1,800 psi243–812 in³/min
Variable Oil Flow above 1,800 psi46–153 in³/min
Usable Oil Capacity66 gal
Motor4 hp
Motor Speed / ControlVFDM; variable frequency drive 15–60 Hz
Electrical Supply460–480 V, 3-phase, 50–60 Hz
Weight2,025 lb
EVO1240460+
EVO-Series Synchronous Lifting Systems

EVO1240460

REQUEST INFO →
Lifting Points12
Variable Oil Flow below 1,800 psi285–951 in³/min
Variable Oil Flow above 1,800 psi88–292 in³/min
Usable Oil Capacity66 gal
Motor10 hp
Motor Speed / ControlVFDM; variable frequency drive 15–60 Hz
Electrical Supply460–480 V, 3-phase, 50–60 Hz
Weight2,250 lb
PUMP-PER-POINT

EVOP-Series Synchronous Lifting

One pump per cylinder for high flow, smooth synchronized movement and fast high-tonnage lifting.

1 pump per cylinder128–488 in³/min rated4–20 hpUp to 8x faster
+
WHERE IT FITSUse EVOP for heavy, long-stroke or repetitive synchronized lifts where a higher flow rate at every lifting point can materially reduce lift time.
ENERPAC

EVOP-Series Pump-per-Point Synchronous Lifting

3 VARIATIONS

EVOP assigns one hydraulic pump to each cylinder for high flow and close synchronization at heavy lift points. Variable-speed motor control provides smooth movement without repeated valve opening and closing.

Lifting Points per Pump1 cylinder / pump
Maximum Operating Pressure10,000 psi
Flow above 1,800 psi128–488 in³/min
Motor Range4–20 hp
Synchronization AccuracyUp to 0.040 in. / 1.0 mm
Speed BenefitUp to 8x faster than similar traditional multi-point methods
COMMON APPLICATIONSHigh-tonnage and long-stroke synchronized lifting, repeated climbing-jack cycles, heavy equipment separation and projects where lift speed is a major requirement.
COMMON INDUSTRIESMining, infrastructure, heavy transport, industrial plant work, construction, large machinery and engineered heavy lifting.
Select a model aboveIts specifications will appear here.
VIEW ALL 3 MODELS & FULL SPECIFICATIONSEVOP-Series Pump-per-Point Synchronous Lifting
+
EVOP12140J+
EVOP-Series Pump-per-Point Synchronous Lifting

EVOP12140J

REQUEST INFO →
Lifting Points per Pump1 cylinder / pump
Reservoir Capacity10 gal
Oil Flow below 1,800 psi677 in³/min
Oil Flow above 1,800 psi128 in³/min
Motor4 hp
Electrical Supply440–480 V, 3-phase, 60 Hz
Weight685 lb
EVOP140150J+
EVOP-Series Pump-per-Point Synchronous Lifting

EVOP140150J

REQUEST INFO →
Lifting Points per Pump1 cylinder / pump
Reservoir Capacity40 gal
Oil Flow below 1,800 psi793 in³/min
Oil Flow above 1,800 psi244 in³/min
Motor10 hp
Electrical Supply440–480 V, 3-phase, 60 Hz
Weight1,080 lb
EVOP180150J+
EVOP-Series Pump-per-Point Synchronous Lifting

EVOP180150J

REQUEST INFO →
Lifting Points per Pump1 cylinder / pump
Reservoir Capacity40 gal
Oil Flow below 1,800 psi1,037 in³/min
Oil Flow above 1,800 psi488 in³/min
Motor20 hp
Electrical Supply440–480 V, 3-phase, 60 Hz
Weight1,115 lb
SYSTEM CONTROLS & FEEDBACK

Controllers, Stroke Sensors & Load Measurement

System components for communicating between lifting points, measuring stroke and monitoring load.

CLNC12EVO-WSSEVO-SCEVOLCK-12
+
WHERE IT FITSUse these components when configuring or expanding an EVO or EVOP synchronized lifting system.
ENERPAC

EVO / EVOP Controls, Sensors & Communication

12 VARIATIONS

Network controllers, communication cables, stroke sensors and load-cell interfaces provide the feedback and communication required for synchronized lifting.

Network ControllerCLNC12
CommunicationEVO-COMM cable family
Stroke FeedbackEVO-WSS sensors + EVO-SC cables
Load MeasurementEVOLCK-12 supports up to 12 electronic load cells
COMMON APPLICATIONSBuilding or expanding EVO/EVOP synchronized lifting systems, monitoring cylinder stroke and connecting hydraulic power units to the central controller.
COMMON INDUSTRIESHeavy lifting, civil infrastructure, offshore, bridge work, industrial construction and engineered lift projects.
Select a model aboveIts specifications will appear here.
VIEW ALL 12 MODELS & FULL SPECIFICATIONSEVO / EVOP Controls, Sensors & Communication
+
EVOMASTER+
EVO / EVOP Controls, Sensors & Communication

EVOMASTER

REQUEST INFO →
TypeMaster control box
UseControls multiple SFP pumps in a networked synchronous-lifting setup
CLNC12+
EVO / EVOP Controls, Sensors & Communication

CLNC12

REQUEST INFO →
TypeNetwork controller
UseMonitors and controls multi-point synchronized lifting
InterfaceIndustrial touch screen
EVOLCK-12+
EVO / EVOP Controls, Sensors & Communication

EVOLCK-12

REQUEST INFO →
TypeLoad cell connection kit
Load CellsUp to 12 electronic load cells
Weighing AccuracyAs good as 1% of total load
UseAdds electronic load measurement to EVO systems
EVO-COMM-25+
EVO / EVOP Controls, Sensors & Communication

EVO-COMM-25

REQUEST INFO →
TypeCommunication cable
Length82 ft / 25 m
UseConnects network controller / hydraulic power units
EVO-COMM-50+
EVO / EVOP Controls, Sensors & Communication

EVO-COMM-50

REQUEST INFO →
TypeCommunication cable
Length164 ft / 50 m
UseConnects network controller / hydraulic power units
EVO-COMM-75+
EVO / EVOP Controls, Sensors & Communication

EVO-COMM-75

REQUEST INFO →
TypeCommunication cable
Length246 ft / 75 m
UseConnects network controller / hydraulic power units
EVO-COMM-100+
EVO / EVOP Controls, Sensors & Communication

EVO-COMM-100

REQUEST INFO →
TypeCommunication cable
Length328 ft / 100 m
UseConnects network controller / hydraulic power units
EVO-WSS-500+
EVO / EVOP Controls, Sensors & Communication

EVO-WSS-500

REQUEST INFO →
TypeWire stroke sensor
Measuring Range19.7 in. / 500 mm
UseProvides cylinder stroke feedback; one per lifting point
EVO-WSS-1000+
EVO / EVOP Controls, Sensors & Communication

EVO-WSS-1000

REQUEST INFO →
TypeWire stroke sensor
Measuring Range39.4 in. / 1,000 mm
UseProvides cylinder stroke feedback; one per lifting point
EVO-WSS-ADJ+
EVO / EVOP Controls, Sensors & Communication

EVO-WSS-ADJ

REQUEST INFO →
TypeAdjustable wire stroke sensor
Measuring Range0–49.2 in.
UseProvides cylinder stroke feedback
EVO-SC-6+
EVO / EVOP Controls, Sensors & Communication

EVO-SC-6

REQUEST INFO →
TypeStroke sensor cable
Length19.7 ft / 6 m
UseConnects stroke sensor to the control system
EVO-SC-25+
EVO / EVOP Controls, Sensors & Communication

EVO-SC-25

REQUEST INFO →
TypeStroke sensor cable
Length82 ft / 25 m
UseConnects stroke sensor to the control system
COMMON APPLICATIONS

Where Multi-Point Lifting Systems Are Commonly Used

Bridge LiftingRaise bridge decks for bearing replacement, maintenance, levelling or structural work.
Structural LevellingControl several lift points while levelling buildings, modules, silos, foundations and large fabricated structures.
Heavy EquipmentLift or separate high-tonnage machinery, mining equipment and major industrial components.
Stage & Climbing LiftsCoordinate repeated lift cycles for construction, tank work, shipbuilding and climbing-jack applications.
Heavy TransportLevel and position large loads during installation, relocation, module movement and transport projects.
Weighing & Load BalancingUse load feedback to understand load distribution before or during a controlled lift.
Bridge / Caisson LoweringSynchronize controlled lowering as well as lifting where several cylinders share the structure.
Offshore & MarinePrecision lift, balance and launch of large structures where movement between points must remain controlled.
NORTHLAND AIR HYDRAULICS • EDMONTON

Enerpac Multi-Point Lifting Systems in Edmonton

Northland Air Hydraulics can help build the complete lifting system around your project — synchronized pumps, cylinders, hoses, couplers, stroke sensors, controls and pressure/load monitoring. Send us the load, number of lift points, cylinder models or capacities, required stroke, synchronization tolerance and available power.

System SelectionSFP, EVO or EVOP based on control accuracy, flow, number of points and lift speed.
Cylinder MatchingConfirm capacity, stroke, oil requirement, acting type and load-holding requirements.
Controls & FeedbackStroke sensors, communication cables, pressure feedback and load-cell interfaces.
Western CanadaEdmonton-based Enerpac sales, service and heavy-lifting support.
MULTI-POINT LIFTING FAQ

Common Questions

What is the difference between SFP and EVO?

SFP split-flow pumps divide hydraulic flow across several outlets and are an economical option when controlled multi-cylinder movement is required. EVO adds PLC-based closed-loop synchronization, stroke/load limits, data recording and much tighter lift-point accuracy.

How many lifting points can an EVO system control?

A standard EVO hydraulic power unit controls 4, 8 or 12 lifting points. Up to four EVO units can be networked for as many as 48 lifting points.

How many cylinders can networked SFP systems control?

Enerpac's SFP network arrangement can combine up to four pumps and, with the appropriate junction boxes, sensors and controls, can support up to 32 cylinders.

When would EVOP be used instead of EVO?

EVOP uses one pump per cylinder and is intended for applications where higher flow at each lift point can reduce cycle time, especially high-tonnage, long-stroke or repetitive synchronized lifting.

Can different cylinder capacities be used with EVO?

Enerpac states that EVO can be connected to single- or double-acting cylinders with the same or different lifting capacities. The complete system still has to be engineered around the actual load, stroke, oil volume and load distribution.

Can Northland help size a complete synchronized lifting system?

Yes. Send the load, number and location of lift points, cylinder requirements, required travel, desired synchronization, lift speed and available power. Northland can help determine the appropriate Enerpac system and components.

Planning a multi-point lift?

Send Northland the load, lifting-point layout, required travel, synchronization tolerance and equipment you already have.

ASK NORTHLAND →

Back To Enerpac
NORTHLAND SYSTEM BUILDER

BUILD THE REST OF YOUR SETUP

Common components, service options and next steps.
COMMONLY PAIRED WITH
WHAT DO YOU NEED TO DO NEXT?
✓
NOT SURE EVERYTHING
WORKS TOGETHER? CHECK THE SETUP →
↻
DON'T NEED
TO OWN IT? RENT ONE →
⚒
HAVE SOMETHING
THAT'S BROKEN? REPAIR IT →
?
NEED A COMPLETE
SETUP? ASK NORTHLAND →
?
NOT SURE WHAT GOES TOGETHER? Send us the model numbers, photos or equipment you already have. We'll help sort out the rest.
GET HELP →
Get A Quick Quote
